Tria

Who is Tria?

TRIA has been producing granulators for shredding plastics since 1954. Now in its third generation, the family business has grown together with the plastics industry.

Because TRIA focused on film extrusion, thermoforming and blow moulding at an early stage, the company is now one of the leading manufacturers of granulators in this field. In addition, TRIA offers granulators for a wide range of applications in plastics processing.

Customers benefit from technical innovations and the high quality standard, which results in high plant reliability at very low costs. In addition to its headquarters in Cologno Monzese, Italy, TRIA operates its own subsidiaries in China, the USA, Brazil and Germany. There, the GmbH Recycling- und Zerkleinerungsmaschinen operates at the Willich site. In Sao Paulo, the mills are manufactured to European quality standards.

Trias develops customised solutions: Central systems, edge strip system or post-consumer.

TRIA granulators have a screening area of 50 percent of the rotor cutting circle. This area enables a high throughput rate as well as a short dwell time of the material to be ground in the grinding chamber. This results in low noise and dust levels.

TRIA granulators have pre-adjustable knives. The supplied setting gauge helps with the correct presetting. This reduces the downtime of the mill to a minimum. Difficult adjustment work in the mill is no longer necessary.

Hardened grinding chambers increase the service life: TRIA has already equipped the grinding chambers of all models of the 20, 30 and 42 series with a hardened surface in the standard version. The company also offers corresponding solutions for sieves and knives.
When developing machines, TRIA engineers pay strict attention to ensuring that the mills offer an optimal gap between the rotor and stator knives as well as the optimal distance to the screen surface at all times. This ensures the best cutting process at all times. The result is a first-class, homogeneous ground product with very low fines content. With the best cutting quality, the motor power to be installed can be reduced. This reduces the mechanical load on the mill.

All TRIA mills from the 30 series onwards have connections for cooling the grinding chambers. This allows customers who process very hot materials inline to carry out their grinding process without difficulty. The cooling reduces blade wear and prevents hot parts from sticking in the grinding chamber. In addition, this solution is ideally suited for grinding very temperature-sensitive materials.

All TRIA cutting mills are equipped with generously dimensioned precision bearings flanged directly to the grinding chamber housing. In the connections with large, heavy pulleys, the kinetic energy is optimally used to grind the plastic. This enables the use of motors with low installed power and the elimination of an additional pulley. The result is the lowest cost per kg of ground material.


THE TRIA MACHINES

CUTTING MILL JM SERIES 15

Technical sprues, reinforced materials, no fines, minimal noise, homogeneous regrind, easy maintenance. The new JM Series 15 is suitable for in-line grinding of sprues from injection moulding machines.

PROPERTIES

• Robust rotor to ensure a reasonable noise level in production.
• Integrated discharge hopper and screen holder to prevent dust from escaping.
• Grinding chamber in wear-resistant 550HV version.
• Easy and tool-free access from only one side for normal maintenance.
• Easy handling with reduced side dimensions to reduce the space required between SGMs.


CUTTING MILL SERIES 20

The TRIA 20 series is optimally suited for use as a side mill. The open rotor concept also shows its strengths when grinding soft and tough materials. The large sieve surface enables fast discharge, high throughput and a very low percentage of jam in the material to be ground.



PROPERTIES

• Sound-insulated side mills for injection moulders
• Grinding chamber hardened for use with filled thermoplastics
• True shear cut
• Rotating side discs in the grinding chamber
• Constant cutting circle
• Screen area corresponds to 50 % of the rotor cutting circle
• Limit switch-secured, tool-free access to the grinding chamber
• Low-speed rotor
• Grinding chamber opening 320 x 200 mm and 420 x 200 mm

CUTTING MILL SERIES 30

A BM variant achieves a high throughput rate with hollow bodies and also slugs with a compact design. The conventional XT variants are characterised by their wide range of applications. Optionally available with hoppers for plates, tubes, profiles or also with infeed units for film grinding.


PROPERTIES

• XT and BM series for individual applications
• Grinding chambers hardened as standard (750 Vickers)
• Tool-free access, secured with magnetic limit switches
• Rotating side discs in the grinding chamber
• True shear cut
• Cooled grinding chamber
• Sieve width is 50 % of the rotor cutting circle
• Simple, quick cleaning
• Grinding chamber openings 350 x 300 mm and 500 x 300 mm



VERSION XT

These mills are universally suitable for grinding injection moulding waste, film remnants, small and medium-sized missing parts. When regrinding shredded material, the mills have a high throughput capacity.


VERSION BM

Mills of the BM series are designed for use with blowing systems. The tangential grinding chamber inlet ensures reliable feeding of hollow bodies while maintaining a high throughput rate.

CUTTING MILL SERIES 42

The BM variants for hollow bodies are supplemented by the XT variants for numerous ice-setting options for injection moulding waste, film remnants, secondary comminution with high throughputs, shape and bottle grinding. The TR variants with the infeed units are suitable for many applications due to the working widths of up to 1,500 mm.


PROPERTIES

• XT and BM series for individual applications
• Grinding chambers hardened as standard (750 Vickers)
• Tool-free access, secured with magnetic end switches
• Rotating side discs in the grinding chamber
• True shear cut
• Cooled grinding chamber
• Sieve area is 50 percent of the rotor cutting circle
• Simple, quick cleaning
• Grinding chamber openings from 620 x 420 mm to 1500 x 420 mm



XT SERIES

The conventional XT variants are characterised by their wide range of applications: Special machines for the recovery of rigid and flexible extrusion waste, for small moulded parts or heavy injection moulded parts, also for grinding waste that has already been crushed.


BM SERIES

With a BM variant, you can achieve a high throughput rate with hollow bodies and also slugs with a compact design: Special machines for the recovery of blow mould waste, such as sprues, blow mould parts, parison, which are processed directly in the plant under high temperatures. Grinding of moulds and blow-moulded parts separately from the plant. Suitable for large size and light weight injection moulded parts or thermoformed parts.


TR SERIES

All mills of the TR series are equipped with a 5-blade rotor as standard. Machines with feeding device for grinding films, sheets and thermoformed films within the line or separately.

CUTTING MILL SERIES 60

The BM variants for hollow bodies are complemented by the XT variants for injection moulding waste, film remnants, secondary crushing with high throughputs, shape and bottle grinding. The TPL variants are ideally suited for grinding pipes, profiles and plates. The TR variants are suitable for a wide range of film applications due to their working widths of up to 1,600 mm.


PROPERTIES

• XT and BM series for individual applications
• Grinding chambers optionally available in hardened ( 750 Vickers ) version
• Tool-free access, secured with magnetic limit switches
• Rotating side discs in the grinding chamber
• Genuine shear cut
• Cooled grinding chamber
• Sieve diameter is 50 % of the rotor cutting circle
• Simple, quick cleaning
• Grinding chamber openings from 740 x 570 mm to 1600 x 570 mm

VERSION BM

Mills of the BM series are designed for use on blowing systems. The tangential grinding chamber inlet ensures reliable feeding of hollow bodies while maintaining high throughput.

VERSION XT

These mills are universally suitable for grinding injection moulding waste, film remnants, small and medium-sized defective parts. When regrinding shredded material, the mills have a high throughput capacity. In addition, it is possible to use this series with solid steel rotors for lump size reduction or, in this configuration, also as a wet mill.


VERSION TR

The TR versions are used with the infeed units in inline film grinding and are suitable for very many film applications due to the working widths of up to 1,600 mm. All mills of the TR versions are equipped with a 5-blade rotor as standard.



CUTTING MILL SERIES 80

TRIA's Series 80 marks the beginning of the upper class in large-scale granulators. The XT variants are built for injection moulding waste, film remnants, lump grinding or high throughputs. The TR variants are used for inline film grinding and are suitable for a wide range of applications due to their working widths of up to 1,600 mm.


PROPERTIES

• XT and TR series for individual applications
• Grinding chambers optionally available in hardened version
• Solid steel rotors and wet grinding version available
• Rotating side discs in the grinding chamber
• True shear cut and V-rotors
• Cooled grinding chamber
• Sieve diameters amount to 50 % of the rotor cutting circle
• Up to 6 rotor blade rows with 620 mm rotor diameter
• Grinding chamber openings from 1,040 x 800 mm to 1,560 x 800 mm



VERSION XT

The conventional XT versions are characterised by their wide range of applications: For grinding injection moulding waste, film remnants, large and heavy missing parts. In addition, it is possible to use this series with solid steel rotors for lump size reduction or, in this configuration, also as a wet mill. Optionally, the mills are available with hoppers for plates, tubes, profiles or also with intake units for film grinding.


VERSION TR

These versions are available with different feed units and are particularly suitable for inline use in the film sector (BOPP, BOPET, BOPA). The high mechanical stability and the use of high-quality components ensure high reliability with low maintenance. All mills of the TR series are equipped with a 5-blade rotor as standard.


CUTTING MILL SERIES 90

TRIA's 90 series completes the upper class of large mills. The XT variants are ideally suited for numerous applications in the comminution of plastic waste of all kinds. The robustness and high quality ensure trouble-free operation combined with high performance.


PROPERTIES

• XT and TR series for individual use
• Grinding chambers optionally available in hardened version
• Solid steel rotors and wet grinding versions available
• Rotating side discs in the grinding chamber
• True shear cut and V-rotors
• Cooled grinding chamber
• Sieve area is 50 percent of the rotor cutting circle
• Up to 7 rotor blade rows with 800 mm rotor diameter
• Grinding chamber openings from 1,540 x 870 mm to 2,040 x 870 mm



VERSION XT/GR

These mills are universally suitable for grinding injection moulding waste, film remnants, large and heavy missing parts. In addition, it is possible to use this series with solid steel rotors for lump size reduction or, in this configuration, also as wet mills. Optionally, the mills are available with hoppers for plates, tubes, proals or also with feeders for film grinding.

VERSION TR

These versions are available with different feed units and are particularly suitable for inline use in the film sector (BOPP, BOPET, BOPA). The TR versions are used with the feed units both in online and in inline film grinding and are suitable for very many film applications due to the working widths of up to 2,000 mm. All mills of the TR variants are equipped with a 5-blade rotor as standard.

---

How you benefit from Spare parts by CUTMETALL

CUTMETALL products: More than a spare part! Tuning for your machine!

Our spare parts and wear parts are not original equipment manufacturer items (original parts of the machine manufacturers) but rather process-optimized CUTMETALL own brands: A perfect fit. Durable. Economical.

CUTMETALL - partner, problem solver, and process optimizer for the recycling and shredding industries.
